Locking mechanism is morticed into the door leaf, offering a hidden latch when closed
Supplied complete with Euro cylinder nightlatch (cylinder not included)
Supplied with timber or steel door keeps and fixings
Ideal for restricted access areas requiring key entry as mortice lock offers more protection against abuse on internal face
Gives a uniform appearance to external door faces regardless of escape functionality
| Name | Value |
|---|---|
| Brand | Exidor |
| Activation | Push Pad |
| Alarmed | No |
| Bolt Style | Latch |
| Cylinder Detail | Euro |
| Cylinder Included | No |
| Dimensions (mm) | 230 X 140 X 110 |
| Dogged | No |
| Door Height (mm) | 2440 |
| Door Opening | Outward |
| Door Type | Rebated Double Active Leaf, Single, Timber |
| Durability | 200000 |
| Escape Hardware Feature | Morticed |
| Escape Hardware Function | Emergency Hardware |
| Fire Door Approval | Yes |
| Fire Rated | Yes |
| Fire Rated Metal | FD120, FD240 |
| Fire Rated Timber | FD120, FD30, FD60, FD90 |
| Fixings | Fixings Supplied |
| Handing | Universal |
| Keep Detail | Standard |
| Key Retention | N/A |
| Locking Points | 1 |
| Max Door Height (mm) | 2440 |
| Max Door Thickness (mm) | 46 To 51 |
| Max Door Weight (kg) | 200kg |
| Max Door Width (mm) | 1220 |
| Micro Switched | No |
| Mounting Method | Surface Mounted |
| Operation Type | Push |
| Operator Detail | Push Pad |
| Product Subtitle | Introducing The Exidor 306 Push Pad Mortice Actuator With Cylinder Nightlatch. This Emergency Push Pad Features A Hidden Locking Mechanism For Added Security And Is Perfect For Restricted Access Areas. Supplied With Timber Or Steel Door Keeps, It Ensures Reliable Operation While Complying With Safety Standards. |
| Projection (mm) | 83 |
| Standards | CE, EN 1634-1, EN 179, UKCA |
| Style | Push |
| Unit Type | Emergency |
| Feature | Morticed |
| Function | Emergency Hardware |
| Product | Product ID | Attributes |
|---|---|---|
| 306 Push pad mortice actuator with cylinder nightlatch | 15901611 | Suitable Door Type: Timber Finish: Silver |
| 306 Push pad mortice actuator with cylinder nightlatch | 15901637 | Finish: Jet Black (Ral 9005) Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15901638 | Finish: Brown Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15901711 | Finish: White Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15901811 | Finish: Black Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15901911 | Finish: Gold Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15902215 | Finish: Stainless Steel Plate Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15902235 | Finish: Brass Suitable Door Type: Timber |
| 306 Push pad mortice actuator with cylinder nightlatch | 15907570 | Finish: Silver Suitable Door Type: Steel |
Exidor emergency push pad shoot bolt for single doors, supplied with timber or steel door keeps and fixings.
The unit is operated by pushing the pad down into the door face to retract the bolts, the bolts remain retracted until automatically released on closing of the door.
Certified in compliance with EN 179 with suitability for timber doors up to FD120 and metal doors FD120/FD240. Indicate the required finish when ordering.
Exidor emergency push pad latch that is simple to install, supplied with timber or steel door keeps and fixings.
The unit is operated by pushing the pad down into the door face to retract the latch, releasing the pad returns the latch to the rest position.
Certified in compliance with EN 179 with suitability for timber doors up to FD120 and metal doors FD120/FD240.
Indicate the required finish when ordering.
