• Two point locking from adjustable shoot bolts

    Solid stainless steel option available

    Non handed design for versatile ordering and stocking

    Push bar design easily cut to size to suit different door widths

    Range of fully tested outside access devices and accessories available

  • NameValue
    Mounting MethodSurface Mounted
    Operation TypePush
    Operator DetailPush Bar
    Product SubtitleIntroducing The Exidor 702B/30 Push Bar With 2 Point Locking, Designed For High-security Environments Like Government And Military Buildings. This Robust Push Bar Features Adjustable Shoot Bolts For Enhanced Intruder Resistance. Available In Solid Stainless Steel, It Can Be Easily Cut To Fit Various Door Widths.
    Projection (mm)133
    StandardsCE, Certifire, EN 1125, EN 1634-1, UKCA
    StylePanic
    Unit TypePanic
    FunctionShoot Bolt
    BrandExidor
    ActivationPush Bar
    AlarmedNo
    Bolt StyleAdjustable Shoot Bolts
    Cylinder IncludedNo
    Dimensions (mm)1227 X 175 X 106
    DoggedNo
    Door Height (mm)2440
    Door OpeningOutward
    Door TypeMetal, Rebated Double Inactive Leaf, Single, Timber
    Durability200000
    Escape Hardware FunctionShoot Bolt
    Fire Door ApprovalYes
    Fire Rated MetalFD120, FD240
    Fire Rated TimberFD30, FD60
    FixingsFixings Supplied
    HandingUniversal
    Keep DetailStandard
    Key RetentionNo
    Locking Points2
    Max Door Height (mm)2440
    Max Door Thickness (mm)46 To 51
    Max Door Weight (kg)200kg
    Max Door Width (mm)1220
    Micro SwitchedNo
  • ProductProduct IDAttributes
    702B/30 Push bar with 2 point locking15092191
    Finish: Anthracite Grey
    Fire Rated: Metal
    Suitable Door Type: Steel
    702B/30 Push bar with 2 point locking15092195
    Finish: Solid Stainless Steel
    Fire Rated: Metal
    Suitable Door Type: Steel
    702B/30 Push bar with 2 point locking15093191
    Finish: Anthracite Grey
    Fire Rated: Timber
    Suitable Door Type: Timber
    702B/30 Push bar with 2 point locking15093193
    Finish: Solid Stainless Steel
    Fire Rated: Timber
    Suitable Door Type: Timber

Similar products

  • 701BD/30 Push bar rebated double door set with 3 point locking

    Exidor high security panic push bar set for double doors comprising 701B/30 1 point shootbolt (active leaf) and 702B/30 2 point shoot bolts (inactive leaf).  Pushing the bar towards the door retracts the shoot bolts which are kept retracted until the door touches the frame as it completes its closing sweep.  Ideal for large capacity public venues such as sports arenas, where greater intruder resistance is required. Designed for use on doors up to 200kg and up to 1220mm wide, the bars can be cut to size on site to suit each door.  Supplied with timber or steel door keeps and fixings, alternative keeps are also available on request.  Certified in compliance with EN 1125 and suitable for use on FD30/FD60 timber fire doors and FD120/FD240 metal fire doors.

  • 701B/30 Push bar with 1 point locking

    Exidor high security panic push bar set for double doors comprising 701B/30 1 point shootbolt (active leaf) and 702B/30 2 point shoot bolts (inactive leaf).  Pushing the bar towards the door retracts the central horizontal shoot bolt which is kept retracted by the upper rod mechanism until the door touches the frame as it completes its closing sweep.  Ideal for large capacit public venues such as sports arenas, where greater intruder resistance is required. Designed for use on doors up to 200kg and up to 1220mm wide, the bars can be cut to size on site to suit each door.  Supplied with timber or steel door keeps and fixings, alternative keeps are also available on request.  Certified in compliance with EN 1125 and suitable for use on FD30/FD60 timber fire doors and FD120/FD240 metal fire doors.

  • 703B/30 Push bar with 3 point locking

    Exidor high-security three-point locking panic push bar with shoot bolts. Ideal for utilities and data centres, where greater intruder resistance is required. Supplied with timber or steel door keeps and fixings, alternative keeps are also available on request. The unit is operated by pushing the bar down into the door face to retract the bolts, the bolts remain retracted until automatically released on the closing of the door. Certified in compliance with EN 1125 and suitable for use on FD30/FD60 timber doors and FD120/FD240 metal doors. Tested and approved to LPS 1175.  Indicate the required finish when ordering. Microswitch option available - suffix order code with “MS” for microswitch.
  • 704B/30 Push bar with 4 point locking

    Exidor high security four point locking panic push bar with shoot bolts on all 4 door edges.  Pushing the bar towards the door retracts the shoot bolts which are kept retracted  until the door touches the frame as it completes its closing sweep.  Ideal for single doors on government or military buildings, where greater intruder resistance is required. Designed for use on doors up to 200kg and up to 1220mm wide, the bar can be cut to size on site to suit each door.  Supplied with timber or steel door keeps and fixings, alternative keeps are also available on request.  Has been part of successful LPS 1175 dorset testing, is certified in compliance with EN 1125 and suitable for use on FD30/FD60 timber fire doors and FD120/FD240 metal fire doors.

  • 742BD/30 Push bar rebated double door set with 4 point locking

    Exidor high security panic push bar set for double doors comprising 2 horizontal shoot bolts (active leaf) and 702B/30 2 point shoot bolts (inactive leaf).  Pushing the bar towards the door retracts the shoot bolts which is kept retracted until the door touches the frame as it completes its closing sweep.  Ideal for large capacity public venues such as exhibition halls, where greater intruder resistance is required. Designed for use on doors up to 200kg and up to 1220mm wide, the bars can be cut to size on site to suit each door.  Supplied with timber or steel door keeps and fixings, alternative keeps are also available on request.  Certified in compliance with EN 1125 and suitable for use on FD30/FD60 timber fire doors and FD120/FD240 metal fire doors.

  • 743BD/30 Push bar rebated double door set with 5 point locking

    Exidor high security panic push bar set for double doors comprising 3 horizontal shoot bolts (active leaf) and 702B/30 2 point shoot bolts (inactive leaf).  Pushing the bar towards the door retracts the shoot bolts which is kept retracted until the door touches the frame as it completes its closing sweep.  Ideal for large capacity public venues such as factories, where greater intruder resistance is required. Designed for use on doors up to 200kg and up to 1220mm wide, the bars can be cut to size on site to suit each door.  Supplied with timber or steel door keeps and fixings, alternative keeps are also available on request.  Part of successful LPS 1175 doorset testing, certified in compliance with EN 1125 and suitable for use on FD30/FD60 timber fire doors and FD120/FD240 metal fire doors.
